ColorSpace.Named

public static final enum ColorSpace.Named
extends Enum<ColorSpace.Named>

java.lang.Object
↳	java.lang.Enum<android.graphics.ColorSpace.Named>
	↳	android.graphics.ColorSpace.Named

List of common, named color spaces. A corresponding instance of ColorSpace can be obtained by calling get(Named):

 ColorSpace cs = ColorSpace.get(ColorSpace.Named.DCI_P3);

The properties of each color space are described below (see sRGB for instance). When applicable, the color gamut of each color space is compared to the color gamut of sRGB using a CIE 1931 xy chromaticity diagram. This diagram shows the location of the color space's primaries and white point.

See also:

get(Named)

Summary

Enum values
`ColorSpace.Named`	`ACES` `RGB` color space ACES standardized as SMPTE ST 2065-1:2012.
`ColorSpace.Named`	`ACESCG` `RGB` color space ACEScg standardized as Academy S-2014-004.
`ColorSpace.Named`	`ADOBE_RGB` `RGB` color space Adobe RGB (1998).
`ColorSpace.Named`	`BT2020` `RGB` color space BT.2020 standardized as Rec.
`ColorSpace.Named`	`BT709` `RGB` color space BT.709 standardized as Rec.
`ColorSpace.Named`	`CIE_LAB` `Lab` color space CIE Lab*.
`ColorSpace.Named`	`CIE_XYZ` `XYZ` color space CIE XYZ.
`ColorSpace.Named`	`DCI_P3` `RGB` color space DCI-P3 standardized as SMPTE RP 431-2-2007.
`ColorSpace.Named`	`DISPLAY_P3` `RGB` color space Display P3 based on SMPTE RP 431-2-2007 and IEC 61966-2.1:1999.
`ColorSpace.Named`	`EXTENDED_SRGB` `RGB` color space scRGB-nl standardized as IEC 61966-2-2:2003.
`ColorSpace.Named`	`LINEAR_EXTENDED_SRGB` `RGB` color space scRGB standardized as IEC 61966-2-2:2003.
`ColorSpace.Named`	`LINEAR_SRGB` `RGB` color space sRGB standardized as IEC 61966-2.1:1999.
`ColorSpace.Named`	`NTSC_1953` `RGB` color space NTSC, 1953 standard.
`ColorSpace.Named`	`PRO_PHOTO_RGB` `RGB` color space ProPhoto RGB standardized as ROMM RGB ISO 22028-2:2013.
`ColorSpace.Named`	`SMPTE_C` `RGB` color space SMPTE C.
`ColorSpace.Named`	`SRGB` `RGB` color space sRGB standardized as IEC 61966-2.1:1999.

Public methods
`static ColorSpace.Named`	`valueOf(String name)`
`static final Named[]`	`values()`

Inherited methods

From class



    java.lang.Enum

`final Object`	`clone()` Throws CloneNotSupportedException.
`final int`	`compareTo(ColorSpace.Named o)` Compares this enum with the specified object for order.
`final boolean`	`equals(Object other)` Returns true if the specified object is equal to this enum constant.
`final void`	`finalize()` enum classes cannot have finalize methods.
`final Class<ColorSpace.Named>`	`getDeclaringClass()` Returns the Class object corresponding to this enum constant's enum type.
`final int`	`hashCode()` Returns a hash code for this enum constant.
`final String`	`name()` Returns the name of this enum constant, exactly as declared in its enum declaration.
`final int`	`ordinal()` Returns the ordinal of this enumeration constant (its position in its enum declaration, where the initial constant is assigned an ordinal of zero).
`String`	`toString()` Returns the name of this enum constant, as contained in the declaration.
`static <T extends Enum<T>> T`	`valueOf(Class<T> enumType, String name)` Returns the enum constant of the specified enum type with the specified name.

From class



    java.lang.Object

`Object`	`clone()` Creates and returns a copy of this object.
`boolean`	`equals(Object obj)` Indicates whether some other object is "equal to" this one.
`void`	`finalize()` Called by the garbage collector on an object when garbage collection determines that there are no more references to the object.
`final Class<?>`	`getClass()` Returns the runtime class of this `Object`.
`int`	`hashCode()` Returns a hash code value for the object.
`final void`	`notify()` Wakes up a single thread that is waiting on this object's monitor.
`final void`	`notifyAll()` Wakes up all threads that are waiting on this object's monitor.
`String`	`toString()` Returns a string representation of the object.
`final void`	`wait(long millis, int nanos)` Causes the current thread to wait until another thread invokes the `notify()` method or the `notifyAll()` method for this object, or some other thread interrupts the current thread, or a certain amount of real time has elapsed.
`final void`	`wait(long millis)` Causes the current thread to wait until either another thread invokes the `notify()` method or the `notifyAll()` method for this object, or a specified amount of time has elapsed.
`final void`	`wait()` Causes the current thread to wait until another thread invokes the `notify()` method or the `notifyAll()` method for this object.

From interface



    java.lang.Comparable

Enum values

ACES

Android O Developer Preview

ColorSpace.Named ACES

RGB color space ACES standardized as SMPTE ST 2065-1:2012.

Chromaticity	Red	Green	Blue	White point
x	0.73470	0.00000	0.00010	0.32168
y	0.26530	1.00000	-0.07700	0.33767
Property	Value
Name	SMPTE ST 2065-1:2012 ACES
CIE standard illuminant	D60
Opto-electronic transfer function (OETF)	\(C_{ACES} = C_{linear}\)
Electro-optical transfer function (EOTF)	\(C_{linear} = C_{ACES}\)
Range	\([-65504.0, 65504.0]\)

ACES (orange) vs sRGB (white)

ACESCG

Android O Developer Preview

ColorSpace.Named ACESCG

RGB color space ACEScg standardized as Academy S-2014-004.

Chromaticity	Red	Green	Blue	White point
x	0.713	0.165	0.128	0.32168
y	0.293	0.830	0.044	0.33767
Property	Value
Name	Academy S-2014-004 ACEScg
CIE standard illuminant	D60
Opto-electronic transfer function (OETF)	\(C_{ACEScg} = C_{linear}\)
Electro-optical transfer function (EOTF)	\(C_{linear} = C_{ACEScg}\)
Range	\([-65504.0, 65504.0]\)

ACEScg (orange) vs sRGB (white)

ADOBE_RGB

Android O Developer Preview

ColorSpace.Named ADOBE_RGB

RGB color space Adobe RGB (1998).

Chromaticity	Red	Green	Blue	White point
x	0.64	0.21	0.15	0.3127
y	0.33	0.71	0.06	0.3290
Property	Value
Name	Adobe RGB (1998)
CIE standard illuminant	D65
Opto-electronic transfer function (OETF)	\(C_{RGB} = C_{linear}^{\frac{1}{2.2}}\)
Electro-optical transfer function (EOTF)	\(C_{linear} = C_{RGB}^{2.2}\)
Range	\([0..1]\)

Adobe RGB (orange) vs sRGB (white)

BT2020

Android O Developer Preview

ColorSpace.Named BT2020

RGB color space BT.2020 standardized as Rec. ITU-R BT.2020-1.

Chromaticity	Red	Green	Blue	White point
x	0.708	0.170	0.131	0.3127
y	0.292	0.797	0.046	0.3290
Property	Value
Name	Rec. ITU-R BT.2020-1
CIE standard illuminant	D65
Opto-electronic transfer function (OETF)	\(\begin{equation} C_{BT2020} = \begin{cases} 4.5 \times C_{linear} & C_{linear} \lt 0.0181 \\ 1.0993 \times C_{linear}^{\frac{1}{2.2}} - 0.0993 & C_{linear} \ge 0.0181 \end{cases} \end{equation}\)
Electro-optical transfer function (EOTF)	\(\begin{equation} C_{linear} = \begin{cases}\frac{C_{BT2020}}{4.5} & C_{BT2020} \lt 0.08145 \\ \left( \frac{C_{BT2020} + 0.0993}{1.0993} \right) ^{2.2} & C_{BT2020} \ge 0.08145 \end{cases} \end{equation}\)
Range	\([0..1]\)

BT.2020 (orange) vs sRGB (white)

BT709

Android O Developer Preview

ColorSpace.Named BT709

RGB color space BT.709 standardized as Rec. ITU-R BT.709-5.

Chromaticity	Red	Green	Blue	White point
x	0.640	0.300	0.150	0.3127
y	0.330	0.600	0.060	0.3290
Property	Value
Name	Rec. ITU-R BT.709-5
CIE standard illuminant	D65
Opto-electronic transfer function (OETF)	\(\begin{equation} C_{BT709} = \begin{cases} 4.5 \times C_{linear} & C_{linear} \lt 0.018 \\ 1.099 \times C_{linear}^{\frac{1}{2.2}} - 0.099 & C_{linear} \ge 0.018 \end{cases} \end{equation}\)
Electro-optical transfer function (EOTF)	\(\begin{equation} C_{linear} = \begin{cases}\frac{C_{BT709}}{4.5} & C_{BT709} \lt 0.081 \\ \left( \frac{C_{BT709} + 0.099}{1.099} \right) ^{2.2} & C_{BT709} \ge 0.081 \end{cases} \end{equation}\)
Range	\([0..1]\)

BT.709

CIE_LAB

Android O Developer Preview

ColorSpace.Named CIE_LAB

Lab color space CIE L*a*b*. This color space uses CIE XYZ D50 as a profile conversion space.

Property	Value
Name	Generic Lab*
CIE standard illuminant	D50
Range	\(L: [0.0, 100.0], a: [-128, 128], b: [-128, 128]\)

CIE_XYZ

Android O Developer Preview

ColorSpace.Named CIE_XYZ

XYZ color space CIE XYZ. This color space assumes standard illuminant D50 as its white point.

Property	Value
Name	Generic XYZ
CIE standard illuminant	D50
Range	\([-2.0, 2.0]\)

DCI_P3

Android O Developer Preview

ColorSpace.Named DCI_P3

RGB color space DCI-P3 standardized as SMPTE RP 431-2-2007.

Chromaticity	Red	Green	Blue	White point
x	0.680	0.265	0.150	0.314
y	0.320	0.690	0.060	0.351
Property	Value
Name	SMPTE RP 431-2-2007 DCI (P3)
CIE standard illuminant	N/A
Opto-electronic transfer function (OETF)	\(C_{P3} = C_{linear}^{\frac{1}{2.6}}\)
Electro-optical transfer function (EOTF)	\(C_{linear} = C_{P3}^{2.6}\)
Range	\([0..1]\)

DCI-P3 (orange) vs sRGB (white)

DISPLAY_P3

Android O Developer Preview

ColorSpace.Named DISPLAY_P3

RGB color space Display P3 based on SMPTE RP 431-2-2007 and IEC 61966-2.1:1999.

Chromaticity	Red	Green	Blue	White point
x	0.680	0.265	0.150	0.3127
y	0.320	0.690	0.060	0.3290
Property	Value
Name	Display P3
CIE standard illuminant	D65
Opto-electronic transfer function (OETF)	\(\begin{equation} C_{DisplayP3} = \begin{cases} 12.92 \times C_{linear} & C_{linear} \lt 0.0030186 \\ 1.055 \times C_{linear}^{\frac{1}{2.4}} - 0.055 & C_{linear} \ge 0.0030186 \end{cases} \end{equation}\)
Electro-optical transfer function (EOTF)	\(\begin{equation} C_{linear} = \begin{cases}\frac{C_{DisplayP3}}{12.92} & C_{sRGB} \lt 0.039 \\ \left( \frac{C_{DisplayP3} + 0.055}{1.055} \right) ^{2.4} & C_{sRGB} \ge 0.039 \end{cases} \end{equation}\)
Range	\([0..1]\)

Display P3 (orange) vs sRGB (white)

EXTENDED_SRGB

Android O Developer Preview

ColorSpace.Named EXTENDED_SRGB

RGB color space scRGB-nl standardized as IEC 61966-2-2:2003.

Chromaticity	Red	Green	Blue	White point
x	0.640	0.300	0.150	0.3127
y	0.330	0.600	0.060	0.3290
Property	Value
Name	scRGB-nl IEC 61966-2-2:2003
CIE standard illuminant	D65
Opto-electronic transfer function (OETF)	\(\begin{equation} C_{scRGB} = \begin{cases} sign(C_{linear}) 12.92 \times \left\| C_{linear} \right\| & \left\| C_{linear} \right\| \lt 0.0031308 \\ sign(C_{linear}) 1.055 \times \left\| C_{linear} \right\| ^{\frac{1}{2.4}} - 0.055 & \left\| C_{linear} \right\| \ge 0.0031308 \end{cases} \end{equation}\)
Electro-optical transfer function (EOTF)	\(\begin{equation} C_{linear} = \begin{cases}sign(C_{scRGB}) \frac{\left\| C_{scRGB} \right\|}{12.92} & \left\| C_{scRGB} \right\| \lt 0.04045 \\ sign(C_{scRGB}) \left( \frac{\left\| C_{scRGB} \right\| + 0.055}{1.055} \right) ^{2.4} & \left\| C_{scRGB} \right\| \ge 0.04045 \end{cases} \end{equation}\)
Range	\([-0.799..2.399[\)

Extended sRGB (orange) vs sRGB (white)

LINEAR_EXTENDED_SRGB

Android O Developer Preview

ColorSpace.Named LINEAR_EXTENDED_SRGB

RGB color space scRGB standardized as IEC 61966-2-2:2003.

Chromaticity	Red	Green	Blue	White point
x	0.640	0.300	0.150	0.3127
y	0.330	0.600	0.060	0.3290
Property	Value
Name	scRGB IEC 61966-2-2:2003
CIE standard illuminant	D65
Opto-electronic transfer function (OETF)	\(C_{scRGB} = C_{linear}\)
Electro-optical transfer function (EOTF)	\(C_{linear} = C_{scRGB}\)
Range	\([-0.5..7.499[\)

Extended sRGB (orange) vs sRGB (white)

LINEAR_SRGB

Android O Developer Preview

ColorSpace.Named LINEAR_SRGB

RGB color space sRGB standardized as IEC 61966-2.1:1999.

Chromaticity	Red	Green	Blue	White point
x	0.640	0.300	0.150	0.3127
y	0.330	0.600	0.060	0.3290
Property	Value
Name	sRGB IEC61966-2.1 (Linear)
CIE standard illuminant	D65
Opto-electronic transfer function (OETF)	\(C_{sRGB} = C_{linear}\)
Electro-optical transfer function (EOTF)	\(C_{linear} = C_{sRGB}\)
Range	\([0..1]\)

sRGB

NTSC_1953

Android O Developer Preview

ColorSpace.Named NTSC_1953

RGB color space NTSC, 1953 standard.

Chromaticity	Red	Green	Blue	White point
x	0.67	0.21	0.14	0.310
y	0.33	0.71	0.08	0.316
Property	Value
Name	NTSC (1953)
CIE standard illuminant	C
Opto-electronic transfer function (OETF)	\(\begin{equation} C_{BT709} = \begin{cases} 4.5 \times C_{linear} & C_{linear} \lt 0.018 \\ 1.099 \times C_{linear}^{\frac{1}{2.2}} - 0.099 & C_{linear} \ge 0.018 \end{cases} \end{equation}\)
Electro-optical transfer function (EOTF)	\(\begin{equation} C_{linear} = \begin{cases}\frac{C_{BT709}}{4.5} & C_{BT709} \lt 0.081 \\ \left( \frac{C_{BT709} + 0.099}{1.099} \right) ^{2.2} & C_{BT709} \ge 0.081 \end{cases} \end{equation}\)
Range	\([0..1]\)

NTSC 1953 (orange) vs sRGB (white)

PRO_PHOTO_RGB

Android O Developer Preview

ColorSpace.Named PRO_PHOTO_RGB

RGB color space ProPhoto RGB standardized as ROMM RGB ISO 22028-2:2013.

Chromaticity	Red	Green	Blue	White point
x	0.7347	0.1596	0.0366	0.3457
y	0.2653	0.8404	0.0001	0.3585
Property	Value
Name	ROMM RGB ISO 22028-2:2013
CIE standard illuminant	D50
Opto-electronic transfer function (OETF)	\(\begin{equation} C_{ROMM} = \begin{cases} 16 \times C_{linear} & C_{linear} \lt 0.001953 \\ C_{linear}^{\frac{1}{1.8}} & C_{linear} \ge 0.001953 \end{cases} \end{equation}\)
Electro-optical transfer function (EOTF)	\(\begin{equation} C_{linear} = \begin{cases}\frac{C_{ROMM}}{16} & C_{ROMM} \lt 0.031248 \\ C_{ROMM}^{1.8} & C_{ROMM} \ge 0.031248 \end{cases} \end{equation}\)
Range	\([0..1]\)

ProPhoto RGB (orange) vs sRGB (white)

SMPTE_C

Android O Developer Preview

ColorSpace.Named SMPTE_C

RGB color space SMPTE C.

Chromaticity	Red	Green	Blue	White point
x	0.630	0.310	0.155	0.3127
y	0.340	0.595	0.070	0.3290
Property	Value
Name	SMPTE-C RGB
CIE standard illuminant	D65
Opto-electronic transfer function (OETF)	\(\begin{equation} C_{BT709} = \begin{cases} 4.5 \times C_{linear} & C_{linear} \lt 0.018 \\ 1.099 \times C_{linear}^{\frac{1}{2.2}} - 0.099 & C_{linear} \ge 0.018 \end{cases} \end{equation}\)
Electro-optical transfer function (EOTF)	\(\begin{equation} C_{linear} = \begin{cases}\frac{C_{BT709}}{4.5} & C_{BT709} \lt 0.081 \\ \left( \frac{C_{BT709} + 0.099}{1.099} \right) ^{2.2} & C_{BT709} \ge 0.081 \end{cases} \end{equation}\)
Range	\([0..1]\)

SMPTE-C (orange) vs sRGB (white)

SRGB

Android O Developer Preview

ColorSpace.Named SRGB

RGB color space sRGB standardized as IEC 61966-2.1:1999.

Chromaticity	Red	Green	Blue	White point
x	0.640	0.300	0.150	0.3127
y	0.330	0.600	0.060	0.3290
Property	Value
Name	sRGB IEC61966-2.1
CIE standard illuminant	D65
Opto-electronic transfer function (OETF)	\(\begin{equation} C_{sRGB} = \begin{cases} 12.92 \times C_{linear} & C_{linear} \lt 0.0031308 \\ 1.055 \times C_{linear}^{\frac{1}{2.4}} - 0.055 & C_{linear} \ge 0.0031308 \end{cases} \end{equation}\)
Electro-optical transfer function (EOTF)	\(\begin{equation} C_{linear} = \begin{cases}\frac{C_{sRGB}}{12.92} & C_{sRGB} \lt 0.04045 \\ \left( \frac{C_{sRGB} + 0.055}{1.055} \right) ^{2.4} & C_{sRGB} \ge 0.04045 \end{cases} \end{equation}\)
Range	\([0..1]\)

sRGB

Public methods

valueOf

Android O Developer Preview

ColorSpace.Named valueOf (String name)

Parameters
`name`	`String`

Returns
`ColorSpace.Named`

values

Android O Developer Preview

Named[] values ()

Returns
`Named[]`

Interfaces
- SurfaceTexture.OnFrameAvailableListener
Classes
Enums
Exceptions
- SurfaceTexture.OutOfResourcesException

Most visited

Recently visited

Results for

ColorSpace.Named

Summary

Enum values

Public methods

Inherited methods

Enum values

ACES

ACESCG

ADOBE_RGB

BT2020

BT709

CIE_LAB

CIE_XYZ

DCI_P3

DISPLAY_P3

EXTENDED_SRGB

LINEAR_EXTENDED_SRGB

LINEAR_SRGB

NTSC_1953

PRO_PHOTO_RGB

SMPTE_C

SRGB

Public methods

valueOf

values

Interfaces

Classes

Enums

Exceptions
